Standard | IEEE 802.3 10Base - T Ethernet IEEE 802.3U 100Base - Tx/100Base-FX IEEE 802.ab 1000Base - T Ethernet IEEE 802.3Z 1000Base - LX Ethernet |
---|---|
RJ45 Ports | 10/100/1000 Mbps, 2Port. Auto MDI/MDI-X UTP/STP Cat 3,4,5,6 cable EIA/TIA-568 100-Ohm(100m) |
Fiber Ports | 1000 Mbps, 1000Base - LX (LC Connector) Single Mode : 9/125 (~100 km), 20km |
---|---|
LED Indicators Per Unit | Power TX Port(Link/ACT, FDX/HDX, 1000, 100) FX Port(Link/ACT) |
Dip Switch | Internal, Auto-negotiation, 10/100/1000 Mbps Full/Half Duplex, LLCF on/off |
Data Transfer | 1000 Mbps |
---|---|
Temperature | Operation : 0℃ ~ 60℃ / Store : -20℃ ~ 70℃ |
Humidity | 10% ~ 90% (Non-Condensing) |
Input Voltage | DC 7.5V ~ 12V, 1A(Max) |
---|---|
Dimension | 100 x 80 x 30 (W x D x H)(Half Type) 100 x 160 x 30 (W x D x H)(Sub-Rack Type) |
Weight | < 0.3 kg |
Channel | 2 Ch |
